Rear axle 3.08 ratio (Not available with (K5L) Heavy-Duty Trailering Package.)
Suspension Package Premium Smooth Ride
GVWR 7300 lbs. (3311 kg) (Standard on 4WD models.)
Differential heavy-duty locking rear
4-wheel drive
Transfer case active single-speed electronic Autotrac with rotary controls does not include neutral. Cannot be dinghy towed. (Requires (GU4) 3.08 rear axle ratio. Not available on 2WD models or with (K5L) heavy-duty trailering package.)
Battery 660 cold cranking amps with 80 amp hour rating
Alternator 160 amps
Trailering equipment includes trailering hitch platform 7-wire harness with independent fused trailering circuits mated to a 7-way sealed connector and 2" trailering receiver
Recovery hooks front frame-mounted (Included and only available on 2WD models when (Z71) Off-Road Suspension Package is ordered. Standard on 4WD models.)
Suspension front coil-over-shock with stabilizer bar
Suspension rear multi-link with coil springs
Steering power
Brakes 4-wheel antilock 4-wheel disc VAC power
Powertrain grade braking
Wheels 4 - 17" x 7.5" (43.2 cm x 19.1 cm) aluminum 5-spoke with smooth surface and rectangular pockets
Tires P265/70R17 all-season blackwall (Not available with (Z71) Off-Road Suspension Package.)
Wheel 17" (43.2 cm) full-size steel spare
Tire carrier lockable outside spare winch-type mounted under frame at rear
Tire spare P265/70R17 all-season blackwall
Luggage rack side rails roof-mounted Black
Luggage rack center rails roof-mounted Black
Fascia front color-keyed
Fascia rear color-keyed
Moldings color-keyed bodyside
Assist steps Black (Not available with (Z71) Off-Road Suspension Package.)
Headlamps dual halogen composite with automatic exterior lamp control and flash-to-pass feature
Fog lamps front halogen
Mirrors outside heated power-adjustable manual-folding (Mirror caps are color-keyed.)
Glass Solar-Ray deep-tinted (all windows except light-tinted glass on windshield and driver- and front passenger-side glass)
Wiper rear intermittent with washer
Door handles color-keyed
Liftgate with liftglass rear door system with rear-window wiper/washer
Audio system AM/FM stereo with CD player and MP3 playback seek-and-scan digital clock auto-tone control Radio Data System (RDS) speed compensated volume TheftLock auxiliary input jack and USB port (Not available with (PCJ) Sun Entertainment and Destinations Package.)
Audio system feature Bose premium 9-speaker system with subwoofer in center console
Audio system controls rear with 2 headphone jacks (headphones not included) power outlet and controls for volume station selection and media
Audio system feature USB port
SiriusXM Satellite Radio is standard on nearly all 2014 GM models. Enjoy a 3-month trial to the XM All Access package with over 150 channels including commercial-free music all your favorite sports exclusive talk and entertainment. With All Access listen to everything everywhere in your car and on your computer smartphone or tablet. (Not available with (UYS) audio system with navigation. IMPORTANT: The SiriusXM Satellite Radio trial package is not provided on vehicles that are ordered for Fleet Daily Rental ("FDR") use. If you decide to continue your service at the end of your trial subscription the plan you choose will automatically renew and bill at then-current rates until you call 1-866-635-2349 to cancel. See SiriusXM Customer Agreement for complete terms at sirisusxm.com. Other fees and taxes will apply. All fees and programming subject to change.)
Bluetooth® for phone personal cell phone connectivity to vehicle audio system and HMI (Human Machine Interface) with specific steering wheel controls (Deleted when (UE0) OnStar delete is ordered.)
Seats front bucket with leather-appointed seating (AG1) 6-way power driver and (AG2) front passenger seat adjusters adjustable head restraints driver manual lumbar control floor console and rear storage pockets
Seats second row 60/40 split-folding bench 3-passenger with center armrest with 2 cup holders
Seats heated driver and front passenger (Included and only available with (A95) front bucket seats. (AN3) front bucket seats contain integrated seat heaters.)
Seat adjuster driver 6-way power
Seat adjuster front passenger 6-way power
Seats third row 50/50 split-bench 3-passenger removable all-belts-to-seat
Console floor with storage area cup holders and integrated second row audio controls
Headliner cloth
Floor covering color-keyed carpeting
Floor mats color-keyed carpeted first and second row removable
Steering wheel leather-wrapped
Steering wheel controls mounted audio and cruise controls
Warning tones headlamp on key-in-ignition driver and right-front passenger safety belt unfasten and turn signal on
Windows power with driver Express-Down and lockout features
Pedals power-adjustable for accelerator and brake (Includes memory function with (AN3) front bucket seats.)
Door locks power programmable with lockout protection
Remote vehicle starter system includes Remote Keyless Entry
Cruise control electronic with set and resume speed
Theft-deterrent system vehicle PASS-Key III
Heater rear auxiliary with rear passenger heating ducts
Air conditioning tri-zone automatic climate control with individual climate settings for driver and right front passenger
Air conditioning rear auxiliary
Defogger rear-window electric
Power outlets 5 auxiliary 12-volt includes 2 on the instrument panel 1 in the cargo area 1 inside the center console and 1 at the back of the console
Mirror inside rearview auto-dimming with rear camera display
Visors driver and front passenger illuminated vanity mirrors padded with cloth trim extends on rod
Assist handles front passenger and second row outboard
Lighting interior with dome light driver- and passenger-side door switch with delayed entry feature cargo lights door handle or Remote Keyless Entry-activated illuminated entry and map lights in front and second seat positions
StabiliTrak stability control system with traction control includes electronic trailer sway control and hill start assist
Daytime Running Lamps with automatic exterior lamp control
Air bags dual-stage frontal driver and right-front passenger with Passenger Sensing System (right-front passenger air bag status on overhead console) (Always use safety belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
Air bags head curtain side-impact first and second row outboard seating positions with rollover sensor includes third row seating positions with (AS3) passenger third row bench seat (Always use safety belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
Air bags seat-mounted side-impact driver and right-front passenger for thorax and pelvic protection (Always use safety belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
OnStar 6 months of Directions and Connections plan includes Automatic Crash Response Stolen Vehicle Assistance Roadside Assistance and Turn-by-Turn Navigation". Also updated footnote 1 to now read "Visit onstar.com for coverage map details and system limitations. Services vary by model and conditions. (Visit onstar.com for details and system limitations.)
Rear Park Assist with audible warning
Rear Vision Camera (Note: images appear on Navigation screen for units equipped with (UYS) AM/FM stereo with MP3 compatible CD/DVD player and navigation. For units not equipped with Navigation systems images will appear within rearview mirror.)
Safety belts 3-point driver and front passenger in all seating positions
LATCH system (Lower Anchors and Top tethers for CHildren) for child safety seats
Tire Pressure Monitoring System air pressure sensors in each tire with pressure display in Driver Information Center (does not apply to spare tire)
ENGINE VORTEC 5.3L V8 SFI FLEXFUEL
with Active Fuel Management
capable of running on unleaded or up to 85% ethanol (with gas - 320 hp [238.6 kW] @ 5400 rpm
335 lb-ft of torque [452.2 N-m] @ 4000 rpm
with E85 ethanol - 326 hp [243.1 kW] @ 5300 rpm
348 lb-ft of torque [469.8 N-m] @ 4400 rpm)
iron block (STD)
Engine
Vortec 5.3L V8 SFI FlexFuel with Active Fuel Management
iron block
Rear axle
3.08 ratio (Not available with (K5L) Heavy-Duty Trailering Package.)
Suspension Package
Premium Smooth Ride
GVWR
7300 lbs. (3311 kg) (Standard on 4WD models.)
Differential
heavy-duty locking rear
Transfer case
active
single-speed
electronic Autotrac with rotary controls
does not include neutral. Cannot be dinghy towed. (Requires (GU4) 3.08 rear axle ratio. Not available on 2WD models or with (K5L) heavy-duty trailering package.)
Battery
660 cold cranking amps with 80 amp hour rating
Alternator
160 amps
Trailering equipment includes trailering hitch platform
7-wire harness with independent fused trailering circuits mated to a 7-way sealed connector and 2" trailering receiver
Suspension
front coil-over-shock with stabilizer bar
rear multi-link with coil springs
Steering
power
Brakes
4-wheel antilock
4-wheel disc
VAC power
Wheel
17" (43.2 cm) full-size
steel spare
Tire carrier
lockable outside spare winch-type mounted under frame at rear
Fascia
front color-keyed
rear color-keyed
Moldings
color-keyed bodyside
Headlamps
dual halogen composite with automatic exterior lamp control and flash-to-pass feature
Fog lamps
front
halogen
Glass
Solar-Ray deep-tinted (all windows except light-tinted glass on windshield and driver- and front passenger-side glass)
Wiper
rear intermittent with washer
Door handles
color-keyed
Audio system feature
Bose premium 9-speaker system with subwoofer in center console
Bluetooth® for phone personal cell phone connectivity to vehicle audio system and HMI (Human Machine Interface) with specific steering wheel controls (Deleted when (UE0) OnStar
delete is ordered.)
Headliner
cloth
Floor covering
color-keyed carpeting
Steering column
Tilt-Wheel
adjustable with brake/transmission shift interlock
Steering wheel
leather-wrapped
Instrumentation
analog with speedometer
odometer with trip odometer
fuel level
voltmeter
engine temperature
oil pressure and tachometer
Warning tones headlamp on
key-in-ignition
driver and right-front passenger safety belt unfasten and turn signal on
Windows
power with driver Express-Down and lockout features
Pedals
power-adjustable for accelerator and brake (Includes memory function with (AN3) front bucket seats.)
Theft-deterrent system
vehicle
PASS-Key III
Heater
rear auxiliary with rear passenger heating ducts
Defogger
rear-window electric
Visors
driver and front passenger illuminated vanity mirrors
padded with cloth trim
extends on rod
Assist handles
front passenger and second row outboard
Lighting
interior with dome light
driver- and passenger-side door switch with delayed entry feature
cargo lights
door handle or Remote Keyless Entry-activated illuminated entry and map lights in front and second seat positions
StabiliTrak
stability control system with traction control includes electronic trailer sway control and hill start assist
Air bags
dual-stage frontal
driver and right-front passenger with Passenger Sensing System (right-front passenger air bag status on overhead console) (Always use safety belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
head curtain side-impact
first and second row outboard seating positions with rollover sensor
includes third row seating positions with (AS3) passenger third row bench seat (Always use safety belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
seat-mounted side-impact
driver and right-front passenger for thorax and pelvic protection (Always use safety belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
Safety belts
3-point
driver and front passenger in all seating positions
