'4x4' tailgate badge
'TUNDRA' stamped easy lower and lift tailgate
'i-FORCE MAX' hood badge
20-in. gray-painted and machined-finish alloy wheels
5.5-ft. Short Bed
Aluminum-reinforced composite bed construction
Chrome 'TUNDRA' and 'LIMITED' door badges, door handles and window molding color-keyed mirror caps and tailgate spoiler gray-painted overfenders
Chrome 'TUNDRA' and 'SR5' door badges black door handles, window molding, mirror caps, tailgate spoiler and overfenders
Front door handles with touch-sensor lock/unlock feature
Gloss-black-painted A-pillar, except on Midnight Black Metallic and Blueprint
Gray-painted horizontal-bar grille with satin chrome surround
Heated power outside mirrors with turn signal and blind spot warning indicators, and power-folding and reverse tilt-down features auto anti-glare driver's-side mirror only
LED Trailer Reverse Assist (TRA) light
LED center high-mount stop light (CHMSL) with integrated cargo lights
LED fog lights
LED headlights with Daytime Running Lights (DRL), auto on/off feature, and manual leveling adjustment
LED taillights
Power tailgate-release switch located in taillight, key fob and dash with knee-lift assit
Washer-linked variable intermittent windshield wipers
i-FORCE MAX tailgate badge
12.3-in. digital meter with selectable gauge display screens and fuel economy, Driver Assist, vehicle/trip information, and warning messages
60/40 split, folding rear seat with center armrest and cup holders
9-speaker audio system
Acoustic laminated windshield
Backup camera with projected path
Drive Mode Select (DMS) switch and dial
Driver's-seat memory function
Dual zone automatic climate control with air filtration and individual temperature settings for driver and front passenger with S-Flow
Electronic locking fuel door
Fixed center console with gated shift lever, driving controls, four cup holders, and center storage bin
Front 12V auxiliary power outlet
Front and rear LED maplights
Front and rear assist grips
Heated and ventilated front seats
Heated front seats
Illuminated center console storage bin and glove box
Leather-trimmed seats with contrast stitching 8-way power-adjustable driver and front passenger seats with power-adjustable lumbar support
Leather-wrapped manual tilt/telescopic steering wheel with phone, audio, display/infotainment, and Driver Assist controls
Leather-wrapped shift knob
Overhead console with rear window control, sunglasses storage and Safety Connect(R)
Power vertical rear window with defogger and privacy glass
Power windows with one-touch auto up/down and jam protection
Rear-seat air vents
Smart Key System with Push Button Start remote keyless entry with lock, unlock, panic, tailgate release and remote illuminated entry
Soft-touch instrument panel, center console and door surfaces
Thin-bezel auto-dimming rearview mirror with HomeLink(R) universal transceiver
Body/Frame: Active aero front spoiler
Body/Frame: Active grille shutters
Body/Frame: Fully boxed high-strength steel ladder frame
Body/Frame: Hydraulic cab mounts
Body/Frame: Ultra-high-strength steel cabin construction with aluminum hood and front door panels
Brakes: Electric Parking Brake (EPB)
Brakes: Electronically Controlled Braking (ECB) system with integrated regenerative braking
Brakes: Power-assisted, ventilated 13.9-in. front disc brakes with opposed dual-piston brake calipers ventilated 13.6-in. rear disc brakes with single-piston calipers
Drive Modes: Eco, Normal and Sport driving modes
Drive Modes: TOW/HAUL driving modes
Drivetrain: 4WDemand part-time 4-Wheel Drive with electronically controlled 2-speed transfer case (high/low ranges) and Automatic Limited-Slip Differential (Auto LSD)
Engine: i-FORCE MAX 3.4L Twin-Turbo V6 Hybrid 437 hp at 5200 rpm 583 lb.-ft. at 2400 rpm
Exhaust System: Stainless steel exhaust system
Fuel System: D-4ST direct-injection and port-injection fuel system
HV Battery: 288V sealed Nickel-Metal Hydride (Ni-MH) battery with 1.87 kWh capacity
HV Electric Motor: Electric motor power: 48 hp (36 kW)
HV Electric Motor: Electric motor torque: 184 lb.-ft. (250 N m)
HV Electric Motor: Parallel hybrid system with permanent magnet synchronous motor/generator
Ignition System: Conventional 12V starter
Intake: Twin turbochargers with electric wastegate valve actuators and water-cooled intercooler
Off-Road: Engine and body undercovers
Steering: Electric Power Steering (EPS) power-assisted rack-and-pinion
Suspension: Independent double-wishbone front suspension coil spring multi-link rear suspension
Towing: Class-IV towing hitch receiver and wiring harness with 7-pin/4-pin connector
Towing: Integrated Trailer Brake Controller (ITBC) with Multi-Information Display (MID) screen and trailer brake type, gain and manual trailer brake output controls
Towing: Trailer-Sway Control (TSC)
Transmission: 10-speed Electronically Controlled automatic Transmission with intelligence (ECT-i), sequential shift mode, and uphill/downhill shift logic
Valvetrain: 24-valve DOHC aluminum cylinder heads with Dual Variable Valve Timing with intelligence (VVT-i) 3445 c.c. aluminum engine block 85.5 x 100 (mm.) bore x stroke 10.4:1 compression ratio
Toyota Safety Sense 2.5 (TSS 2.5) Pre-Collision System with Pedestrian Detection (PCS w/PD), Full-Speed Range Dynamic Radar Cruise Control (DRCC), Lane Departure Alert with Steering Assist (LDA w/SA), Lane Tracing Assist (LTA), Automatic High Beams (AHB), Road Sign Assist (RSA)
3-point seatbelts for all seating positions driver-side Emergency Locking Retractor (ELR) and Automatic/Emergency Locking Retractor (ALR/ELR) on all passenger seatbelts
Blind Spot Monitor (BSM) with Rear Cross-Traffic Alert (RCTA) and Trailer Merge Warning
Child-protector rear door locks and power window lockout control
Drive-Start Control (DSC)
Driver and front passenger headrests
Eight total airbags, including driver and passenger side, knee and curtain airbags
Front and Rear Parking Assist with Automatic Braking
Hill Start Assist Control (HAC)
LATCH (Lower Anchors and Tethers for CHildren) includes lower anchors on all outboard second-row rear seats
Star Safety System includes Vehicle Stability Control (VSC), Traction Control (TRAC), Anti-lock Brake System (ABS) with Electronic Brake-force Distribution (EBD), Brake Assist (BA) and Smart Stop Technology(R) (SST)
Tire Pressure Monitor System (TPMS)
