Leather Seats
Engine
5.3L Ecotec3 V8 With Active Fuel Management Direct Injection And Variable Valve Timing
Includes Aluminum Block Construction With Flex Fuel Capability
Capable Of Running On Unleaded Or Up To 85% Ethanol (355 Hp [265 Kw] @ 5600 Rpm
383 Lb-Ft Of Torque [518 Nm] @ 4100 Rpm; More Than 300 Lb-Ft Of Torque From 2000 To 5600 Rpm) (Std)
HandsFree/Bluetooth
Keyless Entry
Satellite Radio
Tow-Package
Smart Device Integration
Heated Seats
New Arrival
PACKAGE: Trailering equipment includes trailer hitch, 7-pin and 4-pin connectors
MECHANICAL: Engine, 5.3L EcoTec3 V8 with Active Fuel Management Direct Injection and Variable Valve Timing, includes aluminum block construction with Flex Fuel capability, capable of running on unleaded or up to 85% ethanol (355 hp [265 kW] @ 5600 rpm, 383 lb-ft of torque [518 Nm] @ 4100 rpm; more than 300 lb-ft of torque from 2000 to 5600 rpm)
MECHANICAL: Transmission, 6-speed automatic, electronically controlled with overdrive and tow/haul mode. Includes Cruise Grade Braking and Powertrain Grade Braking
MECHANICAL: Rear axle, 3.08 ratio (Requires (L83) 5.3L EcoTec3 V8 engine.)
MECHANICAL: GVWR, 7200 lbs. (3266 kg) (Requires 4WD models and (L83) 5.3L EcoTec3 V8 engine or (L86) 6.2L EcoTec3 V8 engine. Required with (NHT) Max Trailering Package on 2WD or 4WD models.)
MECHANICAL: Differential, heavy-duty locking rear
MECHANICAL: Transfer case, 4WD, active electronic Autotrac with rotary dial control (Included with 4WD models only.)
MECHANICAL: Suspension Package, Handling/Trailering, heavy-duty includes 46 mm piston monotube shocks and 36mm front stabilizer bar
MECHANICAL: Four wheel drive
MECHANICAL: Cooling, external engine oil cooler
MECHANICAL: Cooling, auxiliary external transmission oil cooler
MECHANICAL: Alternator, 150 amps
MECHANICAL: Battery, heavy-duty 720 cold-cranking amps/80 Amp-hr, maintenance-free with rundown protection and retained accessory power
MECHANICAL: Frame, fully-boxed, hydroformed front section
MECHANICAL: Recovery hooks, front, frame-mounted, black (Included and only available with (Z71) Off-Road Package on 2WD models. Standard on 4WD models.) (Included and only available with (Z71) Off-Road Package on 2WD models. Standard on 4WD models.)
MECHANICAL: Cargo tie downs (4) , movable upper
MECHANICAL: Steering, Electric Power Steering (EPS) assist, rack-and-pinion
MECHANICAL: Brakes, 4-wheel disc with DURALIFE rotors, 4-wheel antilock
MECHANICAL: Exhaust, aluminized stainless-steel muffler and tailpipe
EXTERIOR: Wheels, 18" x 8.5" (45.7 cm x 21.6 cm) polished aluminum
EXTERIOR: Tires, P265/65R18 all-season, blackwall (Needs to be upgraded to All-Terrain tires when (Z71) Off-Road Suspension Package is ordered.)
EXTERIOR: Wheel, full-size spare, 17" x 7" (43.2 cm x 17.8 cm) aluminum (Included and only available with model K15543 and (L83) 5.3L EcoTec3 V8 engine. Not available with 20" wheels or 22" LPO wheels unless (Z71) Off-Road Suspension Package is ordered.)
EXTERIOR: Wheelhouse liners, rear
EXTERIOR: Tire, spare P265/70R17 all-season, blackwall
EXTERIOR: Tire carrier lock keyed cylinder lock that utilizes same key as ignition and door
EXTERIOR: Bumper, front chrome
EXTERIOR: Bumper, rear chrome with rear bumper corner steps
EXTERIOR: CornerStep, rear bumper
EXTERIOR: Moldings, bodyside, chrome
EXTERIOR: Grille surround, chrome (With (GAT) All-Terrain Package grille is body colored.)
EXTERIOR: Headlamps, halogen projector with LED signature
EXTERIOR: Fog lamps, front, halogen
EXTERIOR: Lamps, cargo area, cab mounted with switch on center switch bank
EXTERIOR: Mirrors, outside chrome cap, heated power-adjustable, power-folding and driver-side auto-dimming with integrated turn signal indicators and puddle lamps (includes driver's side spotter mirror)
EXTERIOR: Glass, deep-tinted
EXTERIOR: LED Lighting, cargo box with switch on center switch bank
EXTERIOR: Tailgate and bed rail protection caps, top
EXTERIOR: Tailgate, locking utilizes same key as ignition and door
EXTERIOR: Tailgate, EZ-Lift and Lower
EXTERIOR: Door handles, chrome
ENTERTAINMENT: SiriusXM Satellite Radio and HD Radio SiriusXM Satellite Radio is standard on nearly all 2014 GM models. Enjoy a 3-month trial to the XM All Access package, with over 150 channels including commercial-free music, all your favorite sports, exclusive talk and entertainment. With All Access, listen to everything, everywhere, in your car and on your computer, smartphone or tablet. (If you decide to continue your service at the end of your trial subscription, the plan you choose will automatically renew and bill at then-current rates until you call 1-866-635-2349 to cancel. See SiriusXM Customer Agreement for complete terms at siriusxm.com. Other fees and taxes will apply. All fees and programming subject to change. IMPORTANT: The SiriusXM Satellite Radio trial package is not provided on vehicles that are ordered for Fleet Daily Rental ("FDR") use.)
ENTERTAINMENT: 6-speaker audio system
ENTERTAINMENT: Single-slot CD/MP3 player (Replaced by (U42) rear seat DVD/Blu-Ray Entertainment Package when (U42) is ordered.)
ENTERTAINMENT: Bluetooth for phone personal cell phone connectivity to vehicle audio system (See "gmtotalconnect.com" for phone compatibility info.)
ENTERTAINMENT: Steering wheel audio controls
INTERIOR: Seats, front 40/20/40 leather-appointed split-bench 3-passenger with (KA1) heated seat cushions and seat backs. Includes 10-way power driver and front passenger seat adjusters, including driver/front passenger power recline, driver/front passenger power lumbar, 2-position driver memory and adjustable outboard head restraints.
INTERIOR: Seating, heated driver and front passenger
INTERIOR: Seat, rear 60/40 folding bench (folds up), 3-passenger (includes child seat top tether anchor)
INTERIOR: Floor covering, color-keyed carpeting with rubberized vinyl floor mats (Double Cab and Crew Cabs include second row floor mats)
INTERIOR: Steering column, manual Tilt-Wheel
INTERIOR: Steering wheel, leather-wrapped with audio and cruise controls
INTERIOR: Instrumentation, 6-gauge cluster featuring speedometer, fuel level, engine temperature, tachometer, voltage and oil pressure
INTERIOR: Driver Information Center, 4.2-inch diagonal color display includes driver personalization, warning messages and vehicle information
INTERIOR: Windows, power with driver express up and down and express down on all other windows
INTERIOR: Door locks, power
INTERIOR: Pedals, power-adjustable
INTERIOR: Remote Keyless Entry
INTERIOR: Remote vehicle starter system
INTERIOR: Universal Home Remote
INTERIOR: Cruise control, steering wheel-mounted
INTERIOR: Theft-deterrent system, unauthorized entry
INTERIOR: Air conditioning, dual-zone automatic climate control
INTERIOR: Defogger, rear-window electric
INTERIOR: Power outlet, 110-volt AC
INTERIOR: Mirror, inside rearview auto-dimming
INTERIOR: Visors, driver and front passenger illuminated vanity mirrors
INTERIOR: Assist handle, front passenger on A-pillar
SAFETY: StabiliTrak, stability control system with Proactive Roll Avoidance and traction control, includes electronic trailer sway control and hill start assist
SAFETY: Daytime Running Lamps with automatic exterior lamp control
SAFETY: Air bags, dual-stage frontal airbags for driver and front passenger, seat-mounted side-impact airbags for driver and front outboard passenger, and head-curtain airbags for front and rear outboard seating positions; includes right-front airbag Passenger Sensing System (Always use safety belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owners Manual for more information.)
SAFETY: OnStar, 6 months of Directions and Connections plan includes Automatic Crash Response, Stolen Vehicle Assistance, Roadside Assistance and Turn-by-Turn Navigation (Visit onstar.com for coverage map, details and system limitations. Services vary by model and conditions.)
SAFETY: Rear Vision Camera with dynamic guide lines
SAFETY: Tire Pressure Monitoring System (does not apply to spare tire)
GMC Sierra 1500
Body Style: Crew Cab Pickup
Body Code: E63
Drivetrain: Four Wheel Drive
Trans Order Code: MYC
Trans Type: 6
Trans Description Cont.: Automatic
First Gear Ratio (:1): 4.00
Second Gear Ratio (:1): 2.40
Third Gear Ratio (:1): 1.50
Fourth Gear Ratio (:1): 1.20
Fifth Gear Ratio (:1): 0.90
Sixth Gear Ratio (:1): 0.70
Reverse Ratio (:1): 3.10
Transfer Case Model: Magna MP3023/4
Transfer Case Gear Ratio (:1), High: 1.00
Transfer Case Gear Ratio (:1), Low: 2.72
Passenger Capacity: 6
Front Head Room (in): 42.80
Front Leg Room (in): 45.27
Front Shoulder Room (in): 66.03
Front Hip Room (in): 60.73
Second Head Room (in): 40.50
Second Leg Room (in): 40.93
Second Shoulder Room (in): 65.73
Second Hip Room (in): 60.27
Gross Axle Wt Rating - Front (lbs): 3950
Gross Axle Wt Rating - Rear (lbs): 3950
Curb Weight - Front (lbs): - TBD -
Curb Weight - Rear (lbs): - TBD -
Gross Vehicle Weight Rating Cap (lbs): 7200
Gross Combined Wt Rating (lbs): 12000
EPA Greenhouse Gas Score: - TBD -
Tons/yr of CO2 Emissions @ 15K mi/year: 10.2
Fuel Economy Est-Combined (MPG): 18
EPA Fuel Economy Est - City (MPG): 16
EPA Fuel Economy Est - Hwy (MPG): 22
Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
Dead Weight Hitch - Max Tongue Wt. (lbs): 500
Wt Distributing Hitch - Max Trailer Wt. (lbs): 6600
Wt Distributing Hitch - Max Tongue Wt. (lbs): 990
Fifth Wheel Hitch - Max Trailer Wt. (lbs): - TBD -
Fifth Wheel Hitch - Max Tongue Wt. (lbs): - TBD -
Maximum Trailering Capacity (lbs): 11200
Engine Type: Gas/Ethanol V8
Fuel System: Direct Injection
Engine Order Code: L83
Displacement: 5.3L/325
SAE Net Horsepower @ RPM: 355 @ 5600
SAE Net Torque @ RPM: 383 @ 4100
Engine Oil Cooler: Yes
Cold Cranking Amps @ 0° F (Primary): 720
Maximum Alternator Capacity (amps): 150
Maximum Alternator Watts: - TBD -
Total Cooling System Capacity (qts): - TBD -
Frame Type: Hydroformed
Suspension Type - Front: Independent
Suspension Type - Rear: 2-Stage Multi-Leaf
Spring Capacity - Front (lbs): 3950
Spring Capacity - Rear (lbs): 3950
Axle Type - Front: Independent Driving
Axle Type - Rear: Semi-floating
Axle Capacity - Front (lbs): 3950
Axle Capacity - Rear (lbs): 3950
Axle Ratio (:1) - Front: 3.08
Axle Ratio (:1) - Rear: 3.08
Shock Absorber Diameter - Front (mm): 46.00
Shock Absorber Diameter - Rear (mm): 35.00
Stabilizer Bar Diameter - Front (in): 1.35
Front Tire Order Code: RKX
Rear Tire Order Code: RKX
Spare Tire Order Code: RC4
Front Tire Size: P265/65R18
Rear Tire Size: P265/65R18
Spare Tire Size: P265/70R17
Front Tire Capacity (lbs): - TBD -
Rear Tire Capacity (lbs): - TBD -
Spare Tire Capacity (lbs): - TBD -
Revolutions/Mile @ 45 mph - Front: - TBD -
Revolutions/Mile @ 45 mph - Rear: - TBD -
Revolutions/Mile @ 45 mph - Spare: - TBD -
Front Wheel Size (in): 18 x 8.5
Rear Wheel Size (in): 18 x 8.5
Spare Wheel Size (in): 17 x 7.0
Front Wheel Material: Aluminum
Rear Wheel Material: Aluminum
Spare Wheel Material: Aluminum
Steering Type: Electric Rack & Pinion
Steering Ratio (:1), On Center: - TBD -
Steering Ratio (:1), At Lock: - TBD -
Turning Diameter - Curb to Curb (ft): 47.2
Turning Diameter - Wall to Wall (ft): - TBD -
Brake Type: Pwr
Brake ABS System: 4-Wheel
Disc - Front (Yes or ): Yes
Disc - Rear (Yes or ): Yes
Front Brake Rotor Diam x Thickness (in): 13.00 x 1.18
Rear Brake Rotor Diam x Thickness (in): 13.60 x 0.79
Fuel Tank Capacity, Approx (gal): 26
Fuel Tank Location: - TBD -
Wheelbase (in): 143.50
Length, Overall w/o rear bumper (in): 229.50
Width, Max w/o mirrors (in): 80.00
Height, Overall (in): 73.97
Overhang, Front (in): - TBD -
Overhang, Rear w/o bumper (in): - TBD -
Front Bumper to Back of Cab (in): 150.40
Cab to Axle (in): 31.97
Cab to End of Frame (in): - TBD -
Ground to Top of Load Floor (in): - TBD -
Ground to Top of Frame (in): - TBD -
Frame Width, Rear (in): - TBD -
Ground Clearance, Front (in): - TBD -
Ground Clearance, Rear (in): - TBD -
Cargo Box Length @ Floor (in): 69.33
Cargo Box Width @ Top, Rear (in): - TBD -
Cargo Box Width @ Floor (in): - TBD -
Cargo Box Width @ Wheelhousings (in): 51.03
Cargo Box (Area) Height (in): 21.10
Tailgate Width (in): - TBD -
Cargo Volume (ft³): 53.40
Ext'd Cab Cargo Volume (ft³): - TBD -
133,569 km
Automatic
4WD
Gasoline
5.3L 8 Cylinder Engine
8 Cylinder
Pickup
Owners
