Audio system feature 4-speaker system
Audio system 4.2" diagonal color display AM/FM stereo with USB port and auxiliary jack (Requires (AE7) front 40/20/40 split-bench seat. Not available with (UE1) OnStar or (U2K) SiriusXM Radio.) (STD)
SiriusXM delete
Audio system 4.2" diagonal color display AM/FM stereo with USB port and auxiliary jack (STD)
Lamps rear stop/turn/backup (1-piece assembly) with license plate light
Grille guard screen insect protection (mounted behind grille)
Antenna fixed mast
Grille base molded in color Black
Front fender extension painted body color
Lamps cargo area cab mounted with switch on center switch bank
Lamps Smoked Amber roof marker
Headlamps halogen projector-beam
Paint solid
Assist Steps aluminum
Air Dryer heated
Tire Spare 225/70R19.5G highway blackwall Goodyear Includes (V33) Rim Wrench and handle only tool kit.)
Mirror caps chrome
Air Compressor Accessory Drive
Bumper front chrome
Door handles outside chrome
Tires rear 225/70R19.5G highway blackwall Goodyear Max Axle Load: 15000 lb.
Wheels 19.5" x 6.75" 4-aluminum wheels 8-holes hub piloted Dura-Bright finish is on the outside of the wheel
Mirrors outside heated power-adjustable vertical trailering upper glass manual-folding and extending black. Includes integrated turn signal indicators consisting of 51 square inch flat mirror surface positioned over a 24.5 square inch convex mirror surface with a common head and lower convex spotter glass (convex glass is not heated and not power adjustable) and addition of Auxiliary cargo lamp for backing up (helps to see trailer when backing up with a trailer) and amber auxiliary clearance lamp
Summit White
Paint Scheme Style 1
Tires front 225/70R19.5G highway blackwall Goodyear Max Axle Load: 7940 lb.
Wheel 19.5" x 6.75" spare aluminum 8-holes temporary mounted on frame. Dura-Bright finish is on the outside of the wheel.
Glass deep-tinted
Visors driver and front passenger vinyl
Seat trim Vinyl
Speedometer miles/kilometers
Interior trim Jet Black/Dark Ash (Required and only available with (H2Q/H2R) Dark Ash seats with Jet Black interior accents.)
Cruise control steering wheel-mounted
Door locks power
Air conditioning single-zone
Assist handle front passenger and driver on A-pillars
Floor covering Graphite-colored rubberized-vinyl
Steering wheel urethane
Upfitter switch kit provides up to 4-30 amp circuits to facilitate installation of aftermarket electrical accessories located on the instrument panel
Steering column manual Tilt-Wheel
Seats front 40/20/40 split-bench 3-passenger driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Vinyl has fixed lumbar and cloth has manually adjustable driver lumbar. (STD)
Driver Information Center 3.5-inch diagonal monochromatic display provides warning messages and basic vehicle information (Included and only available with (IO3) Audio System with 4.2" diagonal color display or (IOR) Chevrolet Infotainment System with 7" diagonal color touch-screen.)
Mirror inside rearview manual day/night
Seat Belt Black
Dark Ash seats with Jet Black interior accents Vinyl seat trim
Remote Keyless Entry
Windows power with driver express up and down and express down on all other windows
Emissions 50 state certification
Brakes hydraulic heavy duty Bosch/Meritor/Wabco system with 4-channel (ABS) (Includes (J69) driveline park brake.)
Axle Open rear axle non-locking rear
Capped Fuel Fill
Steering power (Bosch S2 8014 Plus)
GVWR 16500 lb. (7484 kg) (Silverado 4500 HD 2WD Regular Cab models require one of the following combinations: (1) (FTC) 6.25k front axle and (FTW) 6.25k front suspension and (GL4) 11k rear axle and (GR3) 11k rear suspension. (2) (FTC) 6.25k front axle and (FTW) 6.25k front suspension and one of the following rear axles: (HD2) 13.5k rear axle (HD1) 15k rear axle or (J27) 15.5k rear axle and (GR4) 13.5k rear suspension. (3) (FTA) 7k front axle and (FK6) 7k front suspension and (FN1) 10k rear axle or (GL4) 11k rear axle and (GR3) 11k rear suspension or (G40) 12K Rear air suspension. (4) (FTA) 7k front axle and (FK6) 7k front suspension and (HD1) 15k rear axle or (J27) 15.5k rear axle and one of the following rear suspensions: (GR4) 13.5k rear suspension (FU7) 15.5k rear suspension (GP1) 13.5K rear air suspension (GP8) 15.5k rear air suspension (91B) 13.5k LiquidSpring prep single volume rear suspension (91C) 13.5k LiquidSpring prep stacked volume rear suspension (91D) 15.5k LiquidSpring prep single volume rear suspension or (91E) 15.5k LiquidSpring prep stacked volume rear suspension.) (STD)
Emissions USA 50 State certified
Rear wheel drive
Incomplete vehicle
Fuel diesel B20
Axle lubricant rear synthetic oil EmGard FE -75W-90
Rear axle 4.10 ratio Max road speed: 79 MPH
Shock Absorbers rear (Included with (FTC) 6250 lb. front axle.)
Trailering provisions trailering wire harness only trailer combined (Stop/Tail/Turn) connection socket and harness mounted at rear of frame.
Batteries heavy-duty dual 1100 cold-cranking amps includes battery box mounted to left side under cab
Exhaust brake
Trailer brake controller integrated
26000 lb. GCWR (11793 kg)
Front suspension 7000 lb. (3175 kg) multi-leaf includes shock absorbers
4500 HD Series
DPF diesel particulate filter manual regeneration customer regeneration will not be allowed until the DPF load percentage has reached 100% full and a driver information center (DIC) message has been shown
Governor electronic speed sensor set to 79 MPH
Wheelbase 201" (510.5 cm) 120" CA
Battery top post threaded battery jump start stud (located on battery box)
Axle limited slip Dana Spicer Truetrac torque proportioning limited slip
GVWR 16500 lb. (7484 kg) (STD)
Tool kit Rim Wrench and handle only
Fuel tank front and rear 65 gallon total
Rear suspension - Air 15500 lb. (7031 kg) 5.3" ride height with shock absorbers
Rear axle 15000 lb. (6804 kg) Dana Spicer S16-130 single reduction
Axle to End of Frame 75"
Exhaust system straight terminates ahead of rear wheels
Alternator 220 amps
Front axle 7000 lb. Dana Spicer D800-N "I"-beam non-driving
Suspension air control valve air release valve with switch in cab
Power Take-Off (PTO) not installed
Work Truck Preferred Equipment Group includes standard equipment
Daytime Running Lamps with automatic exterior lamp control
Airbags Single-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front outboard seating positions; Includes airbag deactivation switch for front outboard passenger airbag (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
Rear Vision Camera display integrated into Radio (Shipped loose in cab for upfitter installation.)
OnStar delete
Airbag deactivation switch frontal passenger-side (Included and only available with (AY0) airbags.)
Horn dual-note
StabiliTrak Electronic Stability Control System with Traction Control includes Electronic Trailer Sway Control and Hill Start Assist
Brake parking driveline park brake system
Traction control
REAR AXLE 4.10 RATIO
Max road speed: 79 MPH
WORK TRUCK PREFERRED EQUIPMENT GROUP
includes standard equipment
SEATS FRONT 40/20/40 SPLIT-BENCH 3-PASSENGER
driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Vinyl has fixed lumbar and cloth has manually adjustable driver lumbar. (STD)
BATTERY TOP POST THREADED BATTERY JUMP START STUD
(located on battery box)
GVWR 16500 LB. (7484 KG)
(STD)
MIRRORS OUTSIDE HEATED POWER-ADJUSTABLE VERTICAL TRAILERING UPPER GLASS MANUAL-FOLDING AND EXTENDING BLACK.
Includes integrated turn signal indicators consisting of 51 square inch flat mirror surface positioned over a 24.5 square inch convex mirror surface with a common head and lower convex spotter glass (convex glass is not heated and not power adjustable) and addition of Auxiliary cargo lamp for backing up (helps to see trailer when backing up with a trailer) and amber auxiliary clearance lamp
DPF DIESEL PARTICULATE FILTER MANUAL REGENERATION
customer regeneration will not be allowed until the DPF load percentage has reached 100% full and a driver information center (DIC) message has been shown
AUDIO SYSTEM 4.2" DIAGONAL COLOR DISPLAY
AM/FM stereo with USB port and auxiliary jack (STD)
ENGINE DURAMAX 6.6L TURBO-DIESEL V8 B20-DIESEL COMPATIBLE
350 hp @ 2500 rpm
750 lb.-ft. torque @ 1400 rpm (STD)
HIGHWAY SERVICE TRANSMISSION AUTOMATIC CLOSE-RATIO 6 SPD WITH DOUBLE OVERDRIVE ALLISON A1700HS
ratios: 3.10 1ST
1.80 2ND
1.40 3RD
1.00 4TH
0.70 5TH
0.61 6TH Highway Series
WHEELS 19.5" X 6.75" 4-ALUMINUM WHEELS 8-HOLES HUB PILOTED
Dura-Bright finish is on the outside of the wheel
WHEEL 19.5" X 6.75" SPARE ALUMINUM 8-HOLES
temporary mounted on frame. Dura-Bright finish is on the outside of the wheel.
TIRES FRONT 225/70R19.5G HIGHWAY BLACKWALL GOODYEAR
Max Axle Load: 7
940 lb.
TIRES REAR 225/70R19.5G HIGHWAY BLACKWALL GOODYEAR
Max Axle Load: 15
000 lb.
TIRE SPARE 225/70R19.5G HIGHWAY BLACKWALL GOODYEAR
Includes (V33) Rim Wrench and handle only tool kit.)
PAINT SCHEME
STYLE 1
GOVERNOR
ELECTRONIC SPEED SENSOR SET TO 79 MPH
WINDOWS
POWER WITH DRIVER EXPRESS UP AND DOWN AND EXPRESS DOWN ON ALL OTHER WINDOWS
GLASS
DEEP-TINTED
MIRROR CAPS
CHROME
ASSIST STEPS
ALUMINUM
DOOR HANDLES
OUTSIDE
WHEELBASE
201" (510.5 CM)
120" CA
AXLE TO END OF FRAME
75"
FRONT SUSPENSION
7
000 LB. (3
175 KG) MULTI-LEAF
INCLUDES SHOCK ABSORBERS
FRONT AXLE
DANA SPICER D800-N
"I"-BEAM
NON-DRIVING
AXLE
LIMITED SLIP
DANA SPICER TRUETRAC
TORQUE PROPORTIONING LIMITED SLIP
REAR SUSPENSION - AIR
15
500 LB. (7
031 KG)
5.3" RIDE HEIGHT WITH SHOCK ABSORBERS
DARK ASH SEATS WITH JET BLACK INTERIOR ACCENTS
VINYL SEAT TRIM
REAR AXLE
000 LB. (6
804 KG)
AIR DRYER
HEATED
SUSPENSION AIR CONTROL VALVE
AIR RELEASE VALVE WITH SWITCH IN CAB
ALTERNATOR
220 AMPS
EXHAUST SYSTEM
STRAIGHT
TERMINATES AHEAD OF REAR WHEELS
FUEL TANK
FRONT AND REAR
65 GALLON TOTAL
POWER TAKE-OFF (PTO)
NOT INSTALLED
26
000 LB. GCWR (11
793 KG)
HORN
DUAL-NOTE
TOOL KIT
RIM WRENCH AND HANDLE ONLY
BUMPER
FRONT CHROME
PAINT
SOLID
