Audio system feature 2 speakers
PIO Audio System Enhanced audio system with 7" diagonal color touchscreen AM/FM stereo with seek-and-scan and digital clock. Additional features include Bluetooth® capability SiriusXM capable (requires separate SiriusXM tuner plus customer subscription) Apple CarPlay Android Auto capable navigation using Apple CarPlay or Android Auto and Rear Vision Camera. (Port Installed Option) (Includes (UVC) Rear Vision Camera PIO.).
Grille color-keyed bar and grille surround
Tires Rear 11R22.5G standard profile LRR (low rolling resistance) tubeless steel belted radial. Rear Highway traction tread. (Standard on 7500 XD model available on 6500 XD model. Requires (074) 5.57 rear axle ratio and (XUH) 11R22.5G front tires.)
Wheels 22.5 x 8.25 steel painted white (STD)
Grille Silver
Tires front 11R22.5G standard profile LRR (low rolling resistance) tubeless steel belted radial. Front Highway tread. (Standard on 7500 XD model available on 6500 XD model. Requires (074) 5.57 rear axle ratio and (YUH) 11R22.5G rear tires. Front GAWR will be increased from 11000 lbs. to 12000 lbs.)
LED Headlamps
Glass tinted
Arc White
Tires Rear 11R22.5G standard profile LRR (low rolling resistance) tubeless steel belted radial. Rear Highway traction tread.
Tires front 11R22.5G standard profile LRR (low rolling resistance) tubeless steel belted radial. Front Highway tread.
PIO Mirrors outside left-hand and right-hand dual cab-mounted exterior with convex mirrors for 102" wide body. Heated flat and convex with remote controls for flat mirrors (Port Installed Option)
Lighting interior dome
Windshield washer bottle access underhood
Air conditioning single-zone manual integral in-dash mounted
Steering wheel urethane
Floor mats
Windows power
Seat high back driver only air suspension system and fixed passenger seat (STD)
Steering column Tilt-Wheel and telescoping steering column
Cup holders
Cruise control electronic automatic
Seat trim Cloth
Storage door pockets
Storage seatback pockets
Door locks power
PIO Back up alarm (Port Installed Option)
Medium Ash Gray Cloth Seat Trim
PIO Remote Keyless Entry (Port Installed Option)
Vehicle Application Truck
GVWR 33000 lbs. (14969 kg) (Standard and only available on 7500 XD model.) (STD)
Battery dual 750 cold-cranking amps 12 volt maintenance free with threaded post
Incomplete vehicle certification
Drivetrain rear-wheel drive
Fuel Tank 100 Gallon (378L) rectangular aluminum fuel tank mounted on left hand frame rail. Fuel water separator with indicator light.
Rear axle 21000 lbs. (9525 kg) full-floating single-speed with oil lubricated rear wheel-bearings Dana Spicer S21-140 (Standard and only available on 7500 XD model.)
Exhaust single horizontal outlet
Front suspension 12000 lbs. (5450 kg) tapered leaf semi-elliptical steel alloy. Includes shock absorbers with stabilizer bar
Wheelbase 224" (569 cm)
Frame ladder-type channel frame. Full C section straight frame 33.5" (85.1 cm) wide. Yield strength 80000 psi section modulus 12.69 cu.in. and RBM 1015000 lb-ft/in per rail.
Rear axle 5.57 ratio (Standard on 7500 XD model and available on 6500 XD with (XUH) and (YUH) 11R22.5G tires.)
Brakes dual circuit full air drum brakes with 4 channel anti-lock brake system
Front axle 12000 lbs. (5450 kg) Dana E-1254-W
Rear Suspension 21000 lbs. (9525 kg) semi-elliptical steel alloy bolted multi-leaf and shock absorbers
Air cleaner heavy-duty 11" diameter dry paper single element. Air cleaner canister standard with air restriction gauge. Back of cab location.
Alternator 160 amps
Exhaust brake
Rear axle 5.57 ratio
GVWR 33000 lbs. (14969 kg) (STD)
Emissions Federal certification with a 5 year/100K mile warranty. Standard on all models
Preferred Equipment Group includes standard equipment
Fleet processing option
Ship Thru Ocean Freight Surcharge
Daytime Running Lamps
PIO Rear Vision Camera (Port Installed Option)
PIO Fire extinguisher 5.0 lb. Dry chemical BC rated and Safety reflector triangle kit (Port Installed Option)
Park brake air-controlled spring-type
Preferred Equipment Group
