Audio system feature 4-speaker system
Audio system 4.2" diagonal color display AM/FM stereo with USB port and auxiliary jack (Requires (AE7) front 40/20/40 split-bench seat. Not available with (UE1) OnStar or (U2K) SiriusXM Radio.) (STD)
SiriusXM delete
Audio system 4.2" diagonal color display AM/FM stereo with USB port and auxiliary jack (STD)
Lamps rear stop/turn/backup (1-piece assembly) with license plate light
Glass solar absorbing tinted
Grille guard screen insect protection (mounted behind grille)
Mirrors outside high-visibility vertical camper-style Black with manual folding and extension and lower convex spotter glass
Antenna fixed mast
Spare tire delete (STD)
Wheel spare delete
Door handles Black
Front fender extension painted body color
Lamps cargo area cab mounted with switch on center switch bank
Tires rear 225/70R19.5G highway blackwall Pirelli Max Axle Load: 15000 lb. (Requires (XEY) Tires front 225/70R19.5G Highway blackwall Pirelli.) (STD)
Assist steps
Tires front 225/70R19.5G highway blackwall Pirelli Max Axle Load: 7940 lb. (Requires (YEY) Tires rear 225/70R19.5G highway blackwall Pirelli Max Axle Load: 15000 lb. or (YEZ) Tires rear 225/70R19.5G traction blackwall Pirelli Max Axle Load: 15000 lb.) (STD)
Lamps Smoked Amber roof marker
Headlamps halogen projector-beam
Paint solid
Work light circuit provides additional wire for utility light at end of frame
Grille chrome
Tires front 225/70R19.5G highway blackwall Pirelli Max Axle Load: 7940 lb. (STD)
Bumper front chrome
Provision for cab roof-mounted lamp/beacon provides an overhead console mounted switch and electrical wiring tucked beneath the headliner for a body upfitter to connect a body-mounted warning or emergency lamp
Tires rear 225/70R19.5G highway blackwall Pirelli Max Axle Load: 15000 lb. (STD)
Auxiliary harness 3' for headlamps and turn signals
Wheels 19.5" x 6.75" steel White painted 8-holes hub piloted
Summit White
License plate kit front
Paint Scheme Style 1
Visors driver and front passenger vinyl
Seat trim Vinyl
Speedometer miles/kilometers
Interior trim Jet Black/Dark Ash (Required and only available with (H2Q/H2R) Dark Ash seats with Jet Black interior accents.)
Cruise control steering wheel-mounted
Door locks power
Windows manual driver and front passenger
Air conditioning single-zone
Assist handle front passenger and driver on A-pillars
Floor covering Graphite-colored rubberized-vinyl
Steering wheel urethane
Upfitter switch kit provides up to 4-30 amp circuits to facilitate installation of aftermarket electrical accessories located on the instrument panel
Steering column manual Tilt-Wheel
Seats front 40/20/40 split-bench 3-passenger driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Vinyl has fixed lumbar and cloth has manually adjustable driver lumbar. (STD)
Driver Information Center 3.5-inch diagonal monochromatic display provides warning messages and basic vehicle information (Included and only available with (IO3) Audio System with 4.2" diagonal color display or (IOR) Chevrolet Infotainment System with 7" diagonal color touch-screen.)
Mirror inside rearview manual day/night
Seat Belt Black
Dark Ash seats with Jet Black interior accents Vinyl seat trim
Power outlet 110-volt AC
Remote Keyless Entry
Provisions for electrical switch bank consists of (6) two position latching rocker style switch modules with an on/off indicator window. The application of each switch will be defined by the customer/up fitter. Located on Headliner.
Axle to End of Frame 49" (Requires wheelbase (ED5) 201" (ED9) 165" or (ER2) 189". Not available with (G40) (GP1) or (GP8) rear air suspension.)
Emissions 50 state certification
Brakes hydraulic heavy duty Bosch/Meritor/Wabco system with 4-channel (ABS) (Includes (J69) driveline park brake.)
Axle Open rear axle non-locking rear
Capped Fuel Fill
Front axle 6250 lb. (2835 kg) Dana Spicer D800-N "I"-beam non-driving (Requires (FTW) 6250 lb. front suspension. Includes (G68) rear shock absorbers. Not available with rear air suspensions.)
Steering power (Bosch S2 8014 Plus)
Emissions USA 50 State certified
Front suspension 6250 lb. (2835 kg) multi-leaf includes shock absorbers (Not available with LiquidSpring prep or rear air suspensions.) (STD)
Rear wheel drive
Incomplete vehicle
Fuel diesel B20
Axle lubricant rear synthetic oil EmGard FE -75W-90
Rear axle 4.10 ratio Max road speed: 79 MPH
Shock Absorbers rear (Included with (FTC) 6250 lb. front axle.)
Trailering provisions trailering wire harness only trailer combined (Stop/Tail/Turn) connection socket and harness mounted at rear of frame.
Exhaust brake
Trailer brake controller integrated
Batteries heavy-duty dual 1300 cold-cranking amps includes battery box mounted to left side under cab
26000 lb. GCWR (11793 kg)
Front suspension 6250 lb. (2835 kg) multi-leaf includes shock absorbers (STD)
Wheelbase 201" (510.5 cm) 120" CA
Axle limited slip Dana Spicer Truetrac torque proportioning limited slip
Shock Absorbers rear
Fuel tank front and rear 65 gallon total
Rear axle 15500 lb. (7031 kg) Dana Spicer S16-140 single reduction
5500 HD Series
Rear suspension 13500 lb. (6123 kg) multi-leaf vari-rate
GVWR 19500 lb. (8845 kg)
Front axle 6250 lb. (2835 kg) Dana Spicer D800-N "I"-beam non-driving Includes (G68) rear shock absorbers.
Alternator 220 amps
Recovery hooks front frame-mounted black
Exhaust system right side exit ahead of rear wheels
Power Take-Off (PTO) not installed
Work Truck Preferred Equipment Group includes standard equipment
Snow Plow Prep Package includes (UNL) auxiliary harness for headlamps and turn signals (KW5) 220-amp alternator forward lamp wiring harness and (TRW) provision for cab roof mounted lamp/beacon
Daytime Running Lamps with automatic exterior lamp control
Airbags Single-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front outboard seating positions; Includes airbag deactivation switch for front outboard passenger airbag (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
Rear Vision Camera display integrated into Radio (Shipped loose in cab for upfitter installation.)
OnStar delete
Airbag deactivation switch frontal passenger-side (Included and only available with (AY0) airbags.)
Horn dual-note
StabiliTrak Electronic Stability Control System with Traction Control includes Electronic Trailer Sway Control and Hill Start Assist
Brake parking driveline park brake system
Traction control
Snow Plow Prep Package
Unknown
Automatic
2WD
Diesel
6.6 Liter Turbo
Unknown
Pickup
