Audio system feature 4-speaker system
Audio system 4.2" diagonal color display AM/FM stereo with USB port and auxiliary jack (Requires (AE7) front 40/20/40 split-bench seat. Not available with (UE1) OnStar or (U2K) SiriusXM Radio.) (STD)
SiriusXM delete
6-speaker audio system
Audio system 7" diagonal color touch-screen with Chevrolet Infotainment AM/FM stereo with seek-and-scan and digital clock includes Bluetooth® streaming audio for music and select phones. (Includes (UQ3) 6-speaker audio system.
Lamps rear stop/turn/backup (1-piece assembly) with license plate light
Glass solar absorbing tinted
Grille guard screen insect protection (mounted behind grille)
Mirrors outside high-visibility vertical camper-style Black with manual folding and extension and lower convex spotter glass
Antenna fixed mast
Spare tire delete (STD)
Wheel spare delete
Tires rear 225/70R19.5G highway blackwall Goodyear Max Axle Load: 15000 lb. (STD)
Door handles Black
Tires front 225/70R19.5G highway blackwall Goodyear Max Axle Load: 7940 lb. (Requires (YAL) Tires rear 225/70R19.5G highway blackwall Goodyear Max Axle Load: 15000 lb. or (YMF) Tires rear 225/70R19.5G traction blackwall Goodyear Max Axle Load: 15000 lb.) (STD)
Grille base molded in color Black
Wheels 19.5" x 6.75" steel Black painted 8-holes hub piloted (STD)
Lamps cargo area cab mounted with switch on center switch bank
Front fender extension mold-in-color Black (Not available with (FNP) Body color front fender extension.)
Assist steps
Lamps Smoked Amber roof marker
Headlamps halogen projector-beam
Bumper front Black
Paint solid
Tires rear 225/70R19.5G traction blackwall Goodyear Max Axle Load: 15000 lb.
Wheels 19.5" x 6.75" steel Grey painted 8-holes hub piloted
Grille chrome
Bumper front chrome
Provision for cab roof-mounted lamp/beacon provides an overhead console mounted switch and electrical wiring tucked beneath the headliner for a body upfitter to connect a body-mounted warning or emergency lamp
Tires front 225/70R19.5G traction blackwall Goodyear Max Axle Load: 7940 lb.
Auxiliary harness 3' for headlamps and turn signals
Tail lamp wiring harness provisions includes wiring for standard left and right taillamps separate 8 feet of extra cable wiring for left and right body-mounted tail lights
Mirrors outside heated power-adjustable vertical trailering upper glass manual-folding and extending black. Includes integrated turn signal indicators consisting of 51 square inch flat mirror surface positioned over a 24.5 square inch convex mirror surface with a common head and lower convex spotter glass (convex glass is not heated and not power adjustable) and addition of Auxiliary cargo lamp for backing up (helps to see trailer when backing up with a trailer) and amber auxiliary clearance lamp
Wheel 19.5" x 6.75" spare steel Black 8-holes temporary mounted on frame hub piloted
Summit White
License plate kit front
Electrical Provisions rear of frame upfitter body builder wiring includes Sealed Connectors for Tail/Amber Turn/Marker/Backup/Accessory Power/Ground and Sealed Connector for Stop/Turn
Tire Spare 225/70R19.5G traction blackwall Goodyear Includes (V33) Rim Wrench and handle only tool kit.)
Visors driver and front passenger vinyl
Seat trim Vinyl
Speedometer miles/kilometers
Interior trim Jet Black/Dark Ash (Required and only available with (H2Q/H2R) Dark Ash seats with Jet Black interior accents.)
Cruise control steering wheel-mounted
Door locks power
Windows manual driver and front passenger
Air conditioning single-zone
Assist handle front passenger and driver on A-pillars
Driver Information Center 3.5-inch diagonal monochromatic display provides warning messages and basic vehicle information
Floor covering Graphite-colored rubberized-vinyl
Steering wheel urethane
Upfitter switch kit provides up to 4-30 amp circuits to facilitate installation of aftermarket electrical accessories located on the instrument panel
Steering column manual Tilt-Wheel
Seats front 40/20/40 split-bench 3-passenger driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Vinyl has fixed lumbar and cloth has manually adjustable driver lumbar. (STD)
Mirror inside rearview manual day/night
Seat Belt Black
Dark Ash seats with Jet Black interior accents Cloth seat trim
Remote Keyless Entry
Windows power with driver express up and down and express down on all other windows
Front suspension 7500 lb. (3402 kg) multi-leaf includes shock absorbers
Axle to End of Frame 49" (Requires wheelbase (ED5) 201" (ED9) 165" or (ER2) 189". Not available with (G40) (GP1) or (GP8) rear air suspension.)
Emissions 50 state certification
Rear suspension 11000 (4990 kg) multi-leaf vari-rate (STD)
Exhaust system rear exit
4500 HD Series (Included and only available with (C7Y) 14001 lb. GVWR (C5B) 15000 lb. GVWR (C7P) 16000 lb. GVWR or (C7R) 16500 lb. GVWR.) (STD)
Wheelbase 165" (419.1 cm) 84" CA (Requires (F0C) 49" axle to end of frame (F0D) 63" axle to end of frame or (F0K) 91" axle to end of frame. Requires (PCJ) Vocational Specific Heavy Suspension Package when ordering (FTA) 7000 lb. Front axle/(FK6) 7000 lb. Front suspension or (FTL) 8000 lb. Front axle/(FSN) 8000 lb. Front suspension or (FU7) 15500 lb. rear suspension.) (STD)
Alternator 150 amps
Brakes hydraulic heavy duty Bosch/Meritor/Wabco system with 4-channel (ABS) (Includes (J69) driveline park brake.)
Axle Open rear axle non-locking rear
Capped Fuel Fill
Steering power (Bosch S2 8014 Plus)
Fuel tank rear only 40 gallon mounted between frame side rails and behind rear axle
Emissions USA 50 State certified
Incomplete vehicle
Fuel diesel B20
Axle lubricant rear synthetic oil EmGard FE -75W-90
GVWR 16500 lb. (7484 kg) (Silverado 4500 HD 4WD models require one of the following combinations: (1) (FTB) 7.5k front axle and (FTV) 7.5k front suspension and (FN1) 10k rear axle or (GL4) 11k rear axle and (GR3) 11k rear suspension. (2) (FTB) 7.5k front axle and (FTV) 7.5k front suspension and (HD1) 15k rear axle or (J27) 15.5k rear axle and one of the following rear suspensions: (GR4) 13.5k rear suspension (FU7) 15.5k rear suspension (91B) 13.5k LiquidSpring prep single volume rear suspension (91C) 13.5k LiquidSpring prep stacked volume rear suspension (91D) 15.5k LiquidSpring prep single volume rear suspension or (91E) 15.5k LiquidSpring prep stacked volume rear suspension.) (STD)
Rear axle 4.30 ratio Max road speed: 75 MPH
Front axle 7500 lb. Dana Spicer 60-256 single-reduction front driving
Batteries heavy-duty dual 1100 cold-cranking amps includes battery box mounted to left side under cab
Axle lubricant front synthetic oil EmGard FE-75W-90
Exhaust brake
Four wheel drive
26000 lb. GCWR (11793 kg)
Additional fuel 20 gallons
Trailer brake controller integrated
Battery top post threaded battery jump start stud (located on battery box)
Axle limited slip Dana Spicer Truetrac torque proportioning limited slip
Tool kit Rim Wrench and handle only
Wheelbase 165" (419.1 cm) 84" CA (STD)
Rear suspension 15500 lb. (7031 kg) multi-leaf vari-rate
Trailering provisions trailering wire harness only trailer combined (Stop/Tail/Turn) connection socket and harness mounted at rear of frame.
5500 HD Series
GVWR 19500 lb. (8845 kg)
Rear axle 15500 lb. (7031 kg) Dana Spicer S16-130 single reduction
Alternator 220 amps
Recovery hooks front frame-mounted black
Vocational Specific Heavy Suspension Package Allows the selection of 7000 lb. 8000 lb. front axles and/or 15500 lb. rear spring suspension on trucks that will be upfitted with the following vocational bodies: Utility/Service Bodies Aerial Lift/Bucket bodies Front Plow/Rear Spreader Applications and Landscape Dump Bodies.
Work Truck Preferred Equipment Group includes standard equipment
Snow Plow Prep Package includes (UNL) auxiliary harness for headlamps and turn signals (KW5) 220-amp alternator forward lamp wiring harness and (TRW) provision for cab roof mounted lamp/beacon
Daytime Running Lamps with automatic exterior lamp control
Horn single-note
Airbags Single-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front outboard seating positions; Includes airbag deactivation switch for front outboard passenger airbag (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
OnStar delete
Airbag deactivation switch frontal passenger-side (Included and only available with (AY0) airbags.)
Horn dual-note
Rear Vision Camera display integrated into Radio (Shipped loose in cab for upfitter installation.)
Electronic Stability Control System with Traction Control includes Electronic Trailer Sway Control and Hill Start Assist
Brake parking driveline park brake system
Traction control
REAR AXLE 4.30 RATIO
Max road speed: 75 MPH
WORK TRUCK PREFERRED EQUIPMENT GROUP
includes standard equipment
ELECTRICAL PROVISIONS REAR OF FRAME UPFITTER BODY BUILDER WIRING
includes Sealed Connectors for Tail/Amber Turn/Marker/Backup/Accessory Power/Ground and Sealed Connector for Stop/Turn
SEATS FRONT 40/20/40 SPLIT-BENCH 3-PASSENGER
driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Vinyl has fixed lumbar and cloth has manually adjustable driver lumbar. (STD)
BATTERY TOP POST THREADED BATTERY JUMP START STUD
(located on battery box)
MIRRORS OUTSIDE HEATED POWER-ADJUSTABLE VERTICAL TRAILERING UPPER GLASS MANUAL-FOLDING AND EXTENDING BLACK.
Includes integrated turn signal indicators consisting of 51 square inch flat mirror surface positioned over a 24.5 square inch convex mirror surface with a common head and lower convex spotter glass (convex glass is not heated and not power adjustable) and addition of Auxiliary cargo lamp for backing up (helps to see trailer when backing up with a trailer) and amber auxiliary clearance lamp
WHEELBASE 165" (419.1 CM) 84" CA
(STD)
AUDIO SYSTEM 7" DIAGONAL COLOR TOUCH-SCREEN WITH CHEVROLET INFOTAINMENT
AM/FM stereo with seek-and-scan and digital clock
includes Bluetooth® streaming audio for music and select phones. (Includes (UQ3) 6-speaker audio system.
TAIL LAMP WIRING HARNESS PROVISIONS
includes wiring for standard left and right taillamps
separate 8 feet of extra cable wiring for left and right body-mounted tail lights
ENGINE DURAMAX 6.6L TURBO-DIESEL V8 B20-DIESEL COMPATIBLE
350 hp @ 2700 rpm
700 lb.-ft. torque @ 1600 rpm (STD)
RUGGED DUTY SERVICE TRANSMISSION AUTOMATIC CLOSE-RATIO 6 SPD WITH DOUBLE OVERDRIVE ALLISON A1700RDS
ratios: 3.10 1ST
1.80 2ND
1.40 3RD
1.00 4TH
0.70 5TH
0.61 6TH Rugged Duty Series
VOCATIONAL SPECIFIC HEAVY SUSPENSION PACKAGE
Allows the selection of 7
000 lb.
8
front axles and/or 15
500 lb. rear spring suspension on trucks that will be upfitted with the following vocational bodies: Utility/Service Bodies
Aerial Lift/Bucket bodies
Front Plow/Rear Spreader Applications
and Landscape Dump Bodies.
POWER TAKE OFF ENGINE CONTROL PROVISIONS
Access is available on left-hand and right-hand side
WHEEL 19.5" X 6.75" SPARE STEEL BLACK 8-HOLES
temporary mounted on frame
hub piloted
PROVISION FOR CAB ROOF-MOUNTED LAMP/BEACON
provides an overhead console mounted switch and electrical wiring tucked beneath the headliner for a body upfitter to connect a body-mounted warning or emergency lamp
REAR VISION CAMERA DISPLAY INTEGRATED INTO RADIO
(Shipped loose in cab for upfitter installation.)
SNOW PLOW PREP PACKAGE
includes (UNL) auxiliary harness for headlamps and turn signals
(KW5) 220-amp alternator
forward lamp wiring harness and (TRW) provision for cab roof mounted lamp/beacon
TIRES FRONT 225/70R19.5G TRACTION BLACKWALL GOODYEAR
Max Axle Load: 7
940 lb.
TIRES REAR 225/70R19.5G TRACTION BLACKWALL GOODYEAR
Max Axle Load: 15
TIRE SPARE 225/70R19.5G TRACTION BLACKWALL GOODYEAR
Includes (V33) Rim Wrench and handle only tool kit.)
WINDOWS
POWER WITH DRIVER EXPRESS UP AND DOWN AND EXPRESS DOWN ON ALL OTHER WINDOWS
FRONT AXLE
7
500 LB.
DANA SPICER 60-256
SINGLE-REDUCTION
FRONT DRIVING
REAR SUSPENSION
15
500 LB. (7
031 KG) MULTI-LEAF
VARI-RATE
AXLE
LIMITED SLIP
DANA SPICER TRUETRAC
TORQUE PROPORTIONING LIMITED SLIP
GVWR
19
500 LB. (8845 KG)
DARK ASH SEATS WITH JET BLACK INTERIOR ACCENTS
CLOTH SEAT TRIM
REAR AXLE
031 KG)
DANA SPICER S16-130
SINGLE REDUCTION
TRAILER BRAKE CONTROLLER
INTEGRATED
ENGINE BLOCK HEATER
ALTERNATOR
220 AMPS
ADDITIONAL FUEL
20 GALLONS
WHEELS
19.5" X 6.75"
STEEL
GREY PAINTED
8-HOLES
26
000 LB. GCWR (11
793 KG)
HORN
DUAL-NOTE
AUXILIARY HARNESS
3' FOR HEADLAMPS AND TURN SIGNALS
TRAILERING PROVISIONS
TRAILERING WIRE HARNESS ONLY
TRAILER COMBINED (STOP/TAIL/TURN) CONNECTION SOCKET AND HARNESS MOUNTED AT REAR OF FRAME.
GRILLE
CHROME
TOOL KIT
RIM WRENCH AND HANDLE ONLY
BUMPER
FRONT CHROME
RECOVERY HOOKS
FRONT
FRAME-MOUNTED
BLACK
LICENSE PLATE KIT
PAINT
SOLID
56 km
Automatic
4WD
Diesel
Engine, Duramax 6.6L Turbo-Diese
Unknown
Other
Owners
