SiriusXM delete
Bluetooth® for phone personal cell phone connectivity to vehicle audio system
6-speaker audio system
Single-slot CD/MP3 player
Tires rear 225/70R19.5G highway blackwall Pirelli Max Axle Load: 15000 lb. (Requires (XEY) Tires front 225/70R19.5G Highway blackwall Pirelli.) (STD)
Front fender extension painted body color
Lamps cargo area cab mounted with switch on center switch bank
Grille guard screen insect protection (mounted behind grille)
Antenna fixed mast
Spare tire delete (STD)
Wheel spare delete
Door handles Black
Tires front 225/70R19.5G highway blackwall Pirelli Max Axle Load: 7940 lb. (Requires (YEY) Tires rear 225/70R19.5G highway blackwall Pirelli Max Axle Load: 15000 lb. or (YEZ) Tires rear 225/70R19.5G traction blackwall Pirelli Max Axle Load: 15000 lb.) (STD)
Lamps Smoked Amber roof marker
Headlamps halogen projector-beam
Bumper front chrome
Grille guard screen stone protection (mounted to bumper)
License plate kit front
Paint Scheme Style 1
Fog lamps front halogen
Paint solid
Assist Steps aluminum
Lamps rear LED stop/turn and license plate with incandescent backup lamps
Red Hot
Grille chrome
Tires front 225/70R19.5G highway blackwall Pirelli Max Axle Load: 7940 lb. (STD)
Provision for cab roof-mounted lamp/beacon provides an overhead console mounted switch and electrical wiring tucked beneath the headliner for a body upfitter to connect a body-mounted warning or emergency lamp
Tires rear 225/70R19.5G highway blackwall Pirelli Max Axle Load: 15000 lb. (STD)
Auxiliary harness 3' for headlamps and turn signals
Mirrors outside heated power-adjustable vertical trailering upper glass manual-folding and extending black. Includes integrated turn signal indicators consisting of 51 square inch flat mirror surface positioned over a 24.5 square inch convex mirror surface with a common head and lower convex spotter glass (convex glass is not heated and not power adjustable) and addition of Auxiliary cargo lamp for backing up (helps to see trailer when backing up with a trailer) and amber auxiliary clearance lamp
Mud Flaps front
Wheels 19.5" x 6.75" 6-aluminum wheels 8-holes hub piloted Dura-Bright finish is on the outside of the wheel
Glass deep-tinted
Assist handle front passenger and driver on A-pillars
Floor covering Graphite-colored rubberized-vinyl
Steering wheel urethane
Upfitter switch kit provides up to 4-30 amp circuits to facilitate installation of aftermarket electrical accessories located on the instrument panel
Steering column manual Tilt-Wheel
Seat Belt Black
Visors driver and front passenger vinyl
Seat trim Vinyl
Cruise control steering wheel-mounted
Speedometer miles/kilometers
Interior trim Jet Black/Dark Ash (Required and only available with (H2Q/H2R) Dark Ash seats with Jet Black interior accents.)
Door locks power
Air conditioning single-zone
Driver Information Center 3.5-inch diagonal monochromatic display provides warning messages and basic vehicle information (Included and only available with (IO3) Audio System with 4.2" diagonal color display or (IOR) Chevrolet Infotainment System with 7" diagonal color touch-screen.)
Mirror inside rearview manual day/night
Windows power with driver express up and down and express down on all other windows
Dark Ash seats with Jet Black interior accents Vinyl seat trim
Back-up alarm calibration This calibration will allow installation of an aftermarket back-up alarm by disabling rear perimeter lighting
Power outlet 110-volt AC
Seats front 40/20/40 split-bench cloth or vinyl 3-passenger. Includes driver and front passenger recline with outboard head restraints and center fold-down armrest with storage. Also includes manually adjustable driver lumbar and storage pockets. Includes (AG1) 10-way power seat.)
Remote Keyless Entry
Seat adjuster driver 10-way power
Defogger rear-window electric
Brakes hydraulic heavy duty Bosch/Meritor/Wabco system with 4-channel (ABS) (Includes (J69) driveline park brake.)
Fuel diesel B20
Axle lubricant rear synthetic oil EmGard FE -75W-90
Shock Absorbers rear (Included with (FTC) 6250 lb. front axle.)
Trailering provisions trailering wire harness only trailer combined (Stop/Tail/Turn) connection socket and harness mounted at rear of frame.
Trailer brake controller integrated
Wheelbase 165" (419.1 cm) 84" CA (Requires (F0C) 49" axle to end of frame (F0D) 63" axle to end of frame or (F0K) 91" axle to end of frame. Requires (PCJ) Vocational Specific Heavy Suspension Package when ordering (FTA) 7000 lb. Front axle/(FK6) 7000 lb. Front suspension or (FTL) 8000 lb. Front axle/(FSN) 8000 lb. Front suspension and/or (FU7) 15500 lb. rear suspension.) (STD)
Emissions 50 state certification
Exhaust system right side exit behind rear wheels (Requires (ED9) 165" wheelbase.)
Emissions USA 50 State certified
Rear wheel drive
Incomplete vehicle
Axle Open rear axle non-locking rear
Capped Fuel Fill
Steering power (Bosch S2 8014 Plus)
Exhaust brake
5500 HD Series
GVWR 19500 lb. (8845 kg)
Front axle 8000 lb. Dana/Spicer D800-N "I"-beam non-driving
Batteries heavy-duty dual 1300 cold-cranking amps includes battery box mounted to left side under cab
Front suspension 8000 lb. (3629 kg) multi-leaf includes shock absorbers
Rear axle 15500 lb. (7031 kg)
DPF diesel particulate filter manual regeneration customer regeneration will not be allowed until the DPF load percentage has reached 100% full and a driver information center (DIC) message has been shown
Axle to End of Frame 63"
Battery top post threaded battery jump start stud (located on battery box)
Axle limited slip Dana Spicer Truetrac torque proportioning limited slip
Shock Absorbers rear
Fuel tank front and rear 65 gallon total
Wheelbase 165" (419.1 cm) 84" CA (STD)
Rear suspension 15500 lb. (7031 kg) multi-leaf vari-rate
Rear axle 4.30 ratio Max road speed: 75 MPH
Alternator 220 amps
Recovery hooks front frame-mounted black
34000 lb. GCWR (15422 kg)
Front stabilizer bar
Vocational Specific Heavy Suspension Package Allows the selection of 7000 lb. 8000 lb. front axles and/or 15500 lb. rear spring suspension on trucks that will be upfitted with the following vocational bodies: Utility/Service Bodies Aerial Lift/Bucket bodies Front Plow/Rear Spreader Applications and Landscape Dump Bodies.
Work Truck Preferred Equipment Group includes standard equipment
Snow Plow Prep Package includes (UNL) auxiliary harness for headlamps and turn signals (KW5) 220-amp alternator forward lamp wiring harness and (TRW) provision for cab roof mounted lamp/beacon
Daytime Running Lamps with automatic exterior lamp control
Rear Vision Camera display integrated into Radio (Shipped loose in cab for upfitter installation.)
OnStar delete
Airbag deactivation switch frontal passenger-side (Included and only available with (AY0) airbags.)
Airbags Single-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front outboard seating positions; Includes airbag deactivation switch for front outboard passenger airbag (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
Horn dual-note
Backup alarm (Includes (SFW) SEO Calibration for backup alarm.
StabiliTrak Electronic Stability Control System with Traction Control includes Electronic Trailer Sway Control and Hill Start Assist
Brake parking driveline park brake system
Traction control
Back-Up Camera
Bluetooth® Connection
Stability Control
Power Driver Seat
Unknown
Automatic
2WD
Diesel
8 Cyl
8 Cylinder
Pickup
Owners
