Rear axle 3.42 ratio (Requires (R04) single rear wheel configuration.)
Body standard
Tow/haul mode selector instrument panel-mounted
Rear wheel drive
Emission System 8.5K-10K GVW (Requires (FE9) Federal emissions requirements (YF5) California state emissions requirements or (NE1) Colorado Connecticut Delaware Maine Maryland Massachusetts Minnesota Nevada New Jersey New York Oregon Pennsylvania Rhode Island Vermont or Washington state emissions requirements.)
Battery 600 cold-cranking amps maintenance-free with rundown protection and retained accessory power
Alternator 150 amps
Frame ladder-type
Incomplete vehicle certification
Suspension front independent with coil springs and stabilizer bar
Suspension rear hypoid drive axle with multi-leaf springs
Steering power
Brakes 4-wheel antilock 4-wheel disc
Fuel tank capacity mid-frame and approximately 32 gallons (121.1L)
Exhaust aluminized stainless-steel muffler and tailpipe
Wheels 4 - 16" x 6.5" (40.6 cm x 16.5 cm) 8-lug painted steel heavy-duty (Only available with (R04) single rear wheel configuration.)
Tires front LT245/75R16E all-season blackwall (Requires (R04) single rear wheel configuration. Jack and spare tire equipment bracket are not included.)
Tires rear LT245/75R16E all-season blackwall (Requires (R04) single rear wheel configuration. Jack and spare tire equipment bracket are not included.)
Wheel configuration rear single (Not available with (C7N) 12300 lbs. (5579 kg.) GVWR.)
Bumper front painted Black with step-pad (Deleted when (ZR7) Chrome Appearance Package is ordered.)
Grille Black composite (Not available with (ZR7) Chrome Appearance Package.)
Headlamps dual halogen composite
Flasher heavy duty light emitting diode (LED)
Glass Solar-Ray light-tinted all windows
Mirrors outside delete (Not available with (5Q7) Upfitter option Blank Sail Panel Delete when ordered with (YF2) Ambulance Package.)
Wipers front intermittent wet-arm with pulse washers
License plate kit front
Audio system AM/FM stereo with MP3 player seek-and-scan digital clock TheftLock random select auxiliary jack and 2 front door speakers
Seating arrangement driver and front passenger high-back bucket includes head restraints and vinyl or cloth trim (Not available with (AJ3) driver-side only frontal airbag.)
Seats front bucket with vinyl trim and head restraints includes inboard armrests (Requires (**W) trim. Not available with (ZP0) delete driver and passenger seats. Includes only driver high-back bucket seat with vinyl trim when ordered with (ZX1) driver-only high-back bucket seating arrangement.)
Floor covering Black rubberized-vinyl front
Warning tones headlamp on and key-in-ignition
Oil life monitor
Theft-deterrent system vehicle PASS-Key III
Power outlet 120-volt
Air conditioning single-zone manual
Heater and defogger with front and side window defoggers
Mirror inside rearview includes Rear Vision Camera display (Included and only available with (UVC) Rear Vision Camera.)
Headliner cloth over driver and passenger
Visors driver and front passenger cloth padded
Assist handles driver and right-front passenger
Lighting interior with dome light and door handle-activated switches
Daytime Running Lamps
StabiliTrak traction assistance and vehicle stability enhancement system
Hill Start Assist
Airbags frontal front driver and right front passenger includes passenger-side frontal airbag deactivation switch (Included with (ZX2) driver and right-front passenger high-back bucket seats or (ZP0) driver and passenger temporary seats. Not available with (ZX1) driver only high-back bucket seat or (AJ3) driver-side only frontal airbag. Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
Airbags seat-mounted side-impact for driver and right-front passenger and roof-rail mounted head-curtain side-impact (Included with (C4M) 9900 lb. (4490 kg) GVWR. Available on (JFF) 10100 lb. (4581 kg) GVWR (C7N) 12300 lb. (5579 kg) GVWR and (C7I) 14200 lb. (6441 kg) GVWR. Not available with (B3D) School Bus Package (ANC) Shuttle Bus Package (YF1) RV Package and (9T7) right-hand door delete. Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
Airbag deactivation switch frontal passenger-side (Not available with (AJ3) frontal driver-side only airbag. Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
OnStar and Chevrolet connected services capable (Currently not available to order. Not available with (YF1) RV Package or (YF2) Ambulance Package. Included with (FDR) Fleet Daily Rental order types. Terms and limitations apply. See onstar.com or dealer for details.)
Rear Vision Camera camera and cable shipped loose (Display included with (DRJ) inside rearview mirror.)
Tire Pressure Monitor System (does not monitor spare tires) (Required with (C4M) 9900 lbs. (4490 kg) GVWR and (R04) single rear 4 - 16" x 6.5" (40.6 cm x 16.5 cm) wheels.)
OnStar Basics (OnStar Fleet Basics for Fleet) Drive confidently with core OnStar services including remote commands built-in voice assistance real-time traffic and navigation and Automatic Crash Response to help if you're in need. (Requires (UE1) OnStar. OnStar Basics includes remote commands Navigation Voice Assistance and Automatic Crash Response for eligible vehicles with compatible software. OnStar Basics is standard for 8 years; OnStar plan working electrical system cell reception and GPS signal required. OnStar links to emergency services. Service coverage varies with conditions and location. Service availability features and functionality vary by device and software version. See onstar.com for details and limitations.)
ENGINE 6.6L V8
with Direct Injection and Variable Valve Timing
gasoline
(401 hp [299 kW] @ 5200 rpm
464 lb-ft of torque [629 N-m] @ 4000 rpm) (Includes external oil cooler.
Rear axle
3.42 ratio (Requires (R04) single rear wheel configuration.)
Body
standard
GVWR
9900 lbs. (4490 kg) (Includes (R04) single rear wheel configuration. Not available with (R05) dual rear wheel combination. Reference the Engine/Axle page for availability.)
Tow/haul mode selector
instrument panel-mounted
Cooling
external engine oil cooler
Emission System
8.5K-10K GVW (Requires (FE9) Federal emissions requirements
(YF5) California state emissions requirements or (NE1) Colorado
Connecticut
Delaware
Maine
Maryland
Massachusetts
Minnesota
Nevada
New Jersey
New York
Oregon
Pennsylvania
Rhode Island
Vermont or Washington state emissions requirements.)
Battery
600 cold-cranking amps maintenance-free with rundown protection and retained accessory power
Alternator
150 amps
Frame
ladder-type
Suspension
front independent with coil springs and stabilizer bar
rear hypoid drive axle with multi-leaf springs
Steering
power
Brakes
4-wheel antilock
4-wheel disc
Fuel tank capacity
mid-frame and approximately 32 gallons (121.1L)
Exhaust
aluminized stainless-steel muffler and tailpipe
Wheel configuration
rear
single (Not available with (C7N) 12
300 lbs. (5579 kg.) GVWR.)
Bumper
front painted Black with step-pad (Deleted when (ZR7) Chrome Appearance Package is ordered.)
Grille
Black composite (Not available with (ZR7) Chrome Appearance Package.)
Headlamps
dual halogen composite
Flasher
heavy duty light emitting diode (LED)
Glass
Solar-Ray light-tinted
all windows
Mirrors
outside delete (Not available with (5Q7) Upfitter option Blank Sail Panel Delete when ordered with (YF2) Ambulance Package.)
Wipers
front intermittent wet-arm with pulse washers
License plate kit
front
Cup holders
3 on the engine console cover
Floor covering
Black rubberized-vinyl front
Instrumentation
analog with speedometer
odometer with trip odometer
fuel level
voltmeter
engine temperature and oil pressure
Driver Information Center includes fuel range
average speed
oil life
fuel used
ice warning
engine hours
average fuel economy
tachometer and maintenance reminders
Warning tones
headlamp on and key-in-ignition
Theft-deterrent system
vehicle
PASS-Key III
Air conditioning
single-zone manual
Headliner
cloth
over driver and passenger
Visors
driver and front passenger
padded
Assist handles
driver and right-front passenger
Lighting
interior with dome light and door handle-activated switches
StabiliTrak
traction assistance and vehicle stability enhancement system
Brake/transmission shift interlock for automatic transmissions
